FEATURES:
* auto-release turn button.
* Concealed screw mounting
* 3" Rose assembly with steel plate provides strength.
* Individual spring on each side to prevent lever sag, maintain reliability, reduce maintenance.
* Extra long lever for easy operation
* 6 pin "C" keyway cylinder.  Available with Interchangeable Core.
* Steel mounting plate provides strength.
* Anti-pry shield.
* UL 1 Hour 1/2" Throw Grade 2 deadlatch completely reversible for flat door.

Door Prep: Cross bore 2-1/8" , Edge bore 1" Latch face 1"x2-1/4".
Backset: Adjustable  2-3/8" or 2-3/4".
Door Thickness: Adjustable 1-3/8" -- 2" .
Cylinder: 6-Pin removable core . Schlage "C " keyway or Kwikset and other options available.
Handing: Completely reversible.
Face plates: 1"x2-1/4"square corner standard. Round corner and other options available.
Strikes: 2-1/4" full lip square corner standard. Round corner and other options available.
Bolt: 1/2" throw, Nickel plated.
ANSI/BHMA: A156.2 Grade 2.
