FEATURES:
* ADA Ergonomic thumb turn.
* 2-1/2" dia. steel two-piece design security ring insert. exceeds ANSI Grade 2 security against hammer and crowbar prying attacks. turns free with any removal attempt.
* High precision pick resistant solid brass 6 pin tumbler plug "C". Brass key nickel plated Meets ANSI Grade 2 Security to prevent  key cylinder from being knocked out.
* 2mm thick steel mounting plate.
* Sturdy, steel latch case.
* Brass bolt nickel plated
* Fixed backset 1" (25mm) deadbolt with hardened steel core exceeds ANSI Grade 2 Security against kick-in and saw attacks.
* Designed to be installed on metal door conveniently. Only one hole is needed on door edge.

Door Prep: Cross bore 2-1/8" , Edge bore 1" Latch face 1"x2-1/4" .
Backset: 2-3/4" standard, 2-3/8" optional.
Door Thickness: Adjustable 1-3/8" -- 2" .
Cylinder: 5-Pin or 6-Pin removable core . Schlage "C " keyway or Kwikset and other options available.
Face plates: 1"x2-1/4" square corner standard. Round corner and other options available.
Strikes: 1-1/8"x2-3/4" square corner standard. Round corner and other options available.
Bolt: 1" throw. Brass bolt, Nickel plated.
ANSI/BHMA: A156.5 Grade 2.
